AC Feeder Cabinet
Industrial-Grade GGD NR System Power Distribution (20KW-400KW)
AC Feeder Cabinet
Conluxs AC Feeder Cabinet · GGD NR System · 20KW-400KW
Product Overview
The Conluxs AC Feeder Cabinet is a robust power distribution solution built on the GGD NR system standard. Supporting a wide power range from 20KW to 400KW, it provides reliable AC power distribution for telecom base stations, data centers, and industrial facilities. Each cabinet is engineered with high-quality MCCBs, copper busbars, and comprehensive surge protection.
Key Technical Features
- GGD NR Standard: Fully compliant with GGD low-voltage switchgear standards for reliable industrial power distribution.
- Wide Power Range: Configurable from 20KW to 400KW with modular breaker and busbar configurations.
- Comprehensive Protection: Integrated surge protection, overload protection, and short-circuit protection per outgoing feeder.
- Modular Design: Hot-swappable feeder modules with front-access maintenance reducing downtime during expansions.
What Is It
AC Feeder Cabinet — a GGD NR standard power distribution cabinet supporting 20KW to 400KW for reliable AC power distribution.
Key Applications
Telecom base stations, data centers, and industrial facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| System Standard | GGD NR |
| Power Range | 20KW - 400KW |
| Rated Voltage | AC 380V / 400V |
| Rated Frequency | 50Hz / 60Hz |
| Rated Current (Main Bus) | Up to 6300A |
| Breaking Capacity | 50kA / 65kA / 80kA |
| Protection Rating | IP30 / IP40 (Indoor) |
| Busbar Material | T2 Copper |
Frequently Asked Questions
What is the AC Feeder Cabinet?
It is a power distribution solution built on the GGD NR system standard, supporting a power range from 20KW to 400KW.
What system standard does it use?
The GGD NR standard, fully compliant with GGD low-voltage switchgear standards.
What protection does it provide?
Integrated surge protection, overload protection, and short-circuit protection per outgoing feeder.
What is the main bus rated current?
Up to 6300A.
Ready to Deploy AC Feeder Cabinets?
Download the complete technical datasheet or request the full product catalog. Our team will follow up within 48 hours.
